Product Description
TECHNICAL SPECIFICATION.
| Model: | WQH-TS09(NA) |
| Materials: | #304 Stainless Steel |
| Power supply: | 110/220Vac, 50/60Hz |
| Logic voltage: | 24Vdc |
| Rated Power: | 80W |
| Operating temperature: | -45°C to +65°C |
| Interface: | RS485 |
| Relative humidity: | less 90% Non-condensing |
| Flow rate: | 30 passages/minute |
| Installation Environment: | Internal or external IP43 |
| Net weight: | 35 kg |
| Dimension: | 420*330*980mm |
| Arm Length: | 600mm |
| MCBF : | >500 Million Times |
| Approved Certificate: | ISO9001 & CE |
APPLICATION.
•Building Sites.
•Offices.
•Banks.
•Exhibition Centres.
•Toilets.
•Museums.
•Administrative Buildings.
•Retail Outlets.
•Railway Terminals.
•Airports, etc.
OPERATING MODES.
The WQ-TR/S/201 turnstile can operate in 3 different modes.
1). Access permanently free, in either or both directions.
2). Access permanently mechanically locked, in either or both directions.
3). Electrically controlled access.
All above operation modes include the arm dropping function providing free and unobstructed safe passage for users in case of power failure.
Mode of operation to be clearly defined at the time of order.
ADVANTAGES AT A GLANCE.
•Low cost.
•Drop arm as standard.
•Robust.
•Reliable.
•LED directional indicator.
•User friendly.
•Compact, small footprint.
•Easy to install.
•Easily integrated with any access control system offering N/O or N/C volt free contact.
•Low power consumption.
DIMENSIONS.
•Length: 420mm.
•Width: 330mm.
•Height: 980mm.
•Arm Length: 600mm.
WORK TO BE PROVIDED BY OTHERS.
•All electrical and control cable requirements.
•All ducts, conducts, containment.
•All foundations, bases.
•Installation.
•Suitable fixings.
DIMENSION SPECIFICATION.
Packaging & Shipping
Packaging & Delivery
Packaging: Honeycomb board box or Plywood board
Delivery: 5 working days after payment
